TANK-101B/BW Embedded System
Page 14
The equipment is intended for installation in a RESTRICTED ACCESS LOCATION.
ƒ Access can only be gained by SERVICE PERSONS or by USERS who have
been instructed about the reasons for the restrictions applied to the location
and about any precautions that shall be taken.
ƒ Access is through the use of a TOOL or lock and key, or other means of
security, and is controlled by the authority responsible for the location.
3.2 CF Card Installation
To install the CF card, please follow the steps below:
Step 1: Locate the CF card slot on the front panel of the TANK-101B/BW.
Step 2: Remove the CF card slot cover by removing the two retention screws (Figure
3-1 ).
Figure 3-1: CF Card Slot
Step 3: Insert the CF card into the slot (Figure 3-2).
