TANK-101B/BW Embedded System
Page 4
Specifications
Display 1 x VGA port
Resolution Up to 2048x1536 @ 60 Hz (D525 model)
Up to 1400x1050 @ 60 Hz (N455 model)
Audio 1 x Line-out port
1 x Mic-in port
CAN-bus 2 x CAN-bus ports with isolation
Expansions One PCIe Mini card slot (reserved for wireless module)
Storage One 2.5” SATA HDD supported
One CompactFlash® socket
Power Supply 9V~36V DC input
Power Consumption 12 W @ 1.85A (Intel® Atom™ D525 1.8 GHz with 1 MB L2 cache,
1.0 GB DDR3 memory)
Mounting
Wall mount
Operating Temperature -20 °C~60°C (D525 model with CompactFlash®/SSD*)
-20 °C~70°C (N455 model with CompactFlash®/SSD*)
-10 °C~50°C (with Wi-Fi)
*Ambient air speed per IEC-68-2-2 standard
Operating Shock Half-sine wave shock 3G; 11ms; 3 shocks per axis
Operating Vibration MIL-STD-810F 514.5C-1 (HDD)
MIL-STD-810F 514.5C-2 (CF)
Color Cool Gray + Blue
Chassis Construction Aluminum alloy with heavy duty metal
Weight (Net/Gross) 2.1 kg/3.9 kg
Physical Dimensions 248 mm x 153 mm x 44 mm (W x D x H)
Table 1-2: Technical Specifications
