IMBA-C2060 ATX Motherboard

Page 67

Figure 4-17: PS/2 Keyboard/Mouse Connector

4.5.6 Serial Device Connection

The IMBA-C2060 has a single female DB-9 connector on the external peripheral interface

panel for a serial device. Follow the steps below to connect a serial device to the

IMBA-C2060.

Step 1:

Locate the DB-9 connector. The location of the DB-9 connector is shown in

Chapter 3.

Step 2:

Insert the serial connector.

Insert the DB-9 connector of a serial device into

the DB-9 connector on the external peripheral interface. See Figure 4-18.
