Chapter 3 87
Removing the LCD Bezel
1. See “Removing the Battery Pack” on page 56.
2. See “Removing the SD dummy card” on page 56.
3. See “Removing the ExpressCard dummy card” on page 57.
4. See “Removing the Lower Cover” on page 57.
5. See “Removing the WLAN Board Modules” on page 60.
6. See “Removing the Keyboard” on page 69.
7. See “Removing the LCD Module” on page 70.
8. Remove the four upper and the two lower bezel screw caps.
9. Remove the six screws (E) on the LCD module in the order as shown.
Step Size (Quantity) Color Torque
1~6 M2.5 x L5 (6) Black 3.0 kgf-cm
