Chapter 3 65
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Removing the CPU and VGA Heatsink Module
1. See “Removing the Battery Pack” on page 56.
2. See “Removing the Lower Cover” on page 57.
Screw List
Item Screw Color Part No.
A M2 x L3 Black 86.00D29.620
D M2 x L5 Black 86.00E32.725
F M2 x L4 Black 86.00F24.724
H M2.5 x L8 Black 86.00E34.738
MAIN UNIT
KEYBOARD
MAIN
BOARD
Fx2
MAIN UNIT DISASSEMBLY
LCD MODULE
H x 2 Ax7, Fx4
UPPER CASE
Dx9
LEFT AND RIGHT
SPEAKER MODULE
MODEM
BOARD
2xSCREWS
CPU/VGA
THERMAL MODULE
CPU
TOUCH PAD BRACKET
ASSEMBLY
Fx2
TOUCH PAD
BRACKET
LAUNCH BOARD
A x 4
5xCaptive Screws
TOUCH PAD
BOARD
2xSCREWS
