End Tidal Carbon Dioxide (EtCO
2
)
EtCO
2
- 15
Default Settings
When the unit is turned on, the following default EtCO
2
settings are automatically selected and remain in operation until
changed.
Note The power on default settings for the capnogram waveform scale and CO
2
compensation are set in System
Configuration, as are the power-on default settings for alarm limits. See the M Series Configuration Guide for
more information.
EtCO
2
Accessories
The following tables list the accessories available for the M Series Mainstream and Sidestream EtCO
2
monitoring
options.
Table 1: CAPNOSTAT 3 Mainstream CO
2
Accessories
* SPU = Single Patient Use
Parameter Default Setting Range
Averaging Mode 10 seconds 1 breath
10 seconds
20 seconds
High EtCO
2
Alarm Limit 55 mmHg
7.2%
7.3 kPa 5 - 100 mmHg, OFF
0.6 - 13.1%, OFF
0.6 -13.3 kPa, OFF
Low EtCO
2
Alarm Limit 25 mmHg
3.2%
3.3 kPa 0 - 95 mmHg, OFF
0 - 12.5%, OFF
0 -12.6 kPa, OFF
High Respiration Rate Alarm Limit 120 respirations per min. 5 - 150 respirations per min., OFF
Low Respiration Rate Alarm Limit 5 respirations per min. 0 - 100 respirations per min., OFF
Accessory (ZOLL Reorder Part Number) Application
CAPNOSTAT 3 CO
2
Sensor and Cable (8000-0264-01)
Sensor Cable Holding Clips, bag of 5 (8000-0266-01)
SPU Pediatric/Adult Airway Adapter (8000-0260-01) Single patient use, for ET tube sizes > 4.0 mm
SPU Neonatal/Pediatric Airway Adapter (8000-0261-01) Single patient use, for ET tube sizes ≤ 4.0 mm
Reusable Adult Airway Adapter (8000-0262-01) Reusable, for ET tube sizes > 4.0 mm
Reusable Neonatal/Pediatric Airway Adapter (8000-0263-01) Reusable, for ET tube sizes ≤ 4.0 mm
SPU Pediatric/Adult Airway Adapter with Mouthpiece
(8000-0265-01) Single patient use, for non-intubated patients
Capno
2
mask, Large Adult (8000-0761) SPU, for non-intubated large adults
Capno
2
mask, Standard Adult (8000-0760) SPU, for non-intubated adults
Capno
2
mask, Pediatric (8000-0762) SPU, for non-intubated adults pediatric patients
