Patient information, Measurements matrix, Option insert – ZOLL M Series Defibrillator Rev H User Manual
Page 12
OPTION INSERT
9650-0215-01
12-lead - 10
Patient Information
DEVICE ID: MEDIC_1
RECORDED: 11:33:01 15 DEC 99
PATIENT NAME : JOE SMITH
PATIENT ID: 199912150932
PATIENT AGE: 41
PATIENT SEX: Male
Vent. Rate : 72
PR interval 146 ms
QRS Duration: 84 ms
QT/QTc 374 / 409 ms
P-R-T axes 64 39 48
Normal sinus rhythm
Normal ECG
*** Unconfirmed ***
Measurements Matrix
The unit can be configured to print out a measurements matrix, which consists of measurements for each segment of each lead. To
print the measurements matrix at the end of an analysis, the user must change the default setting in the M Series device (see the M
Series Configuration Guide, P/N 9650-0201-01, for more details).
