Specifications
ZOLL M Series Operator’s Guide - Option Insert 23
Specifications
* Neonatal and pediatric NIBP modes available on M Series CCT units only.
a Blood pressure measurements determined with this device are equivalent to those obtained by a trained observer using the
cuff/stethoscope auscultation method, within the limits prescribed by the American National Standard, Electronic or
automated sphygmomanometers (AAMI SP10). To receive a copy of the report containing the AAMI SP10 test results, contact
ZOLL Technical Support at (800) 348-9011 or (978) 421-9655 .
Table 8 General Specifications
Principle of Operation Oscillometric
Warm up Time Operational in less than 10 seconds
Size 8.2" (20.8 cm) high x 10.1" (25.7 cm) wide x 8.0" (20.3 cm) deep
Regulatory Standards ANSI/AAMI SP10-1992;
EN 1060-1: 1996 Specification for Non-invasive sphygmomanometers;
EN 1060-3: 1997;
IEC60601-2-30: 1999
Table 9 NIBP Measurement Specifications
Range
Systolic Adult: 40 – 260 mmHg; 5.3 – 34.7 kPa
Pediatric: 35 – 160 mmHg; 4.7 – 21.3 kPa*
Neonatal: 25 – 130 mmHg; 3.3 – 17.3 kPa*
Diastolic Adult: 20 – 200 mmHg; 2.7 – 26.7 kPa
Pediatric: 20 – 130 mmHg; 2.7 – 17.3 kPa*
Neonatal: 20 – 105 mmHg; 2.7 – 14.0 kPa*
Mean Adult: 20 – 220 mmHg; 2.7 – 29.3 kPa
Pediatric: 20 – 140 mmHg; 2.7 – 18.7 kPa*
Neonatal: 20 – 110 mmHg; 2.7 – 14.7 kPa*
Accuracy Per AAMI SP10 +/- 5 mmHg (0.7 kPa) mean difference;
8 mmHg (1.1 kPa) standard deviation
a
Resolution 1 mmHg; 0.13 kPa
Measurement Cycle Time
Typical: 30 seconds
Worst Case: 180 seconds
Table 10 Pulse Rate Measurement Specifications
Range 35 – 220 pulses per minute
Resolution 1 pulse per minute
