M S ERIES C ONFIGURATION G UIDE
4
Read From Card
Pressing the Read From Card softkey prompts the user to choose either a language or
configuration card. The following screen will be displayed.
To move the highlighted area from LANGUAGE to CONFIGURATION and vice versa, press
the Prev Item and Next Item softkeys. Press the Enter softkey to begin reading and storing the
language settings or configuration settings from the user installed memory card.
If a language card has been read and loaded, the “Card Read” message displays. If a configura-
tion card has been read and loaded, the “Card Read” and “Press Change Config to View” mes-
sages display (see below):
If there is an error reading the memory card, one of the following error messages will be
displayed on the monitor.
Change Config
Pressing the Change Config softkey causes the unit to display the first configuration option
menu.
There are three user configurable features contained within each option menu. (Refer to the
“Configuration Option Tables” section for all available options and default settings).
EROR MESSAGE DEFINITION
CARD READ FAILED No response from card reader
BAD CARD Cannot read from card
WRONG CARD TYPE Card is the wrong type
CONFIG DATA NOT COMPATIBLE Internal software is unable to read card data
NO CARD INSERTED Card is not installed in PCMCIA slot
CARD EMPTY No data on card
6\VWHP&RQILJXUDWLRQ
3UHY
9DOXH
1H[W
9DOXH (QWHU
5HDG:KLFK7\SHRI&DUG"
/$1*8$*(
&21),*85$7,21
6\VWHP&RQILJXUDWLRQ
5HVWRUH
'HIDXOWV
5HDG
)URP
&DUG
3ULQW
&RQILJ
&KDQJH
&RQILJ
([LW
&RQILJ
&DUG5HDG
3UHVV&KDQJH&RQILJWR9LHZ
