Page 2-6 P/N 12555-001 Rev 3
User Guide
Figure 2-7 Removing the LifeBand from the AutoPulse Platform.
4. Remove the LifeBand from the AutoPulse Platform by grasping the LifeBand chest band with the
thumb and index finger of both hands, on either side of the LifeBand band clip. Push in the
guide plate, using both middle fingers. Keeping the guide plate pushed in, pull up the band to
remove the clip from the shaft (see Figure 2-7).
5. Discard the LifeBand as it is a single-use component after patient use. Treat the LifeBand as
contaminated medical waste and dispose of it accordingly. There are no user-serviceable
parts.
Warning: Removing the band clip when the driveshaft is not at its home position (see Figure 2-10)
will result in a permanent User Advisory (45) that the user will not be able to clear. This
may be the case if the LifeBand has been cut. Please refer to Section 2.1.2.1, “Removing a
LifeBand that is Cut or Not in the Home Position” for additional specific instructions before
removing it. Do not continue to remove the LifeBand using the following procedure
without first consulting Section 2.1.2.1.
1
2
Guide Plate
1
2
