3 system components, 1 autopulse platform – ZOLL AutoPulse 100 User Manual
Page 14
Page 1-2
P/N 12555-001 Rev 3
User Guide
Figure 1-1
The AutoPulse System
1.3
System Components
Figure 1-1 shows the main components of the AutoPulse System.
The AutoPulse consists of the following:
•
AutoPulse Platform
•
LifeBand
•
AutoPulse Power System
1.3.1
AutoPulse Platform
The AutoPulse Platform contains the mechanical drive mechanism, control system, and electronics
necessary to generate and control the force required to perform mechanical chest compressions. User
controls and indicators are contained in the User Control Panel.
Figure 1-2 shows the patient surface (front) and back surface details of the AutoPulse Platform. The
AutoPulse Platform features carry handles to facilitate transporting it to the scene of the arrest.
LifeBand
AutoPulse Platform
User Control Panel
Li-Ion Batteries
(Primary and Spare)
NiMH Batteries
(Primary and Spare)
or
Multi-Chemistry
Battery Charger
