23
Mower Pan
Models 927046,053,054,055,056,306,307,308,310
ITEM PART DESCRIPTION QTY.
NO. NO.
ITEM PART DESCRIPTION QTY.
NO. NO.
1 06529700 Nut-Locking-Center .250-20 4
2 02709500 Hinge Plate 2
3 02202900 Bushing (054,056) 1
4 06537100 Nut-Nylon-LockingWing
.312-18 1
5 06439400 Washer-Flat-Steel .328 x .875
x .062 1
6 08307200 Spring-Tension .095 x .50 x
1.0 (054,056) 1
08318500 Spring-Tension .090 x .37 x
.63 (046,053,306,307,310) 1
08314500 Spring-Tension .090 x .37 x
.63 (055,308) 1
7 05706300 Ring-Retaining-External .313
x .025 1
8 03624200 Pin 1
9 02509700 Rear Mounting Bracket
(054,056) 2
10 07411500 Screw-Tapping .31-18 x .50
(54,56)
4
11 00212300 Clevis Pin 3/8 x 2 1
12 06701000 Pin-Hair Internal .08 x .38 x
1.42 1
13 02708300 Swivel Bracket 1
14 02520400 Pan Head Chute Extension
(054,056) 1
52707000 28” Deflector with Decals
(046,053,306,307,310) 1
53508200 32” Deflector with Decals
(055,308) 1
15 06219900 Bolt Round Head Square
Neck .25-20 x .75 Gr. 5 4
16 06219800 Bolt Round Head Square
Neck .25-20 x 1.00 1
17 52708700 28” Mower Pan Head with
Deflector & Decals
(046,053,306,307,310)
1
52708800 28” Mower Pan Head Service
Assembly (046,053,306, 1
307,310)
52702200 30” Mower Pan Head with
Deflector & Decals
(054,056)
1
52709400 30” Mower Pan Head
Assembly (054,056) 1
52709600 32” Mower Pan Head with
Deflector & Decals
(055,308)
1
52709700 32” Mower Pan Head
Assembly Retrofit
(055,308)
1
18 06212200 Bolt-Round Head Square
Neck .31-18 x .62 7
19 06529800 Nut-Locking-Center .31-18 2
20 06530400 Nut-Flange .312-18 4
21 06713500 Pin-Hair .088 x .18 x 1.18 4
22 02747500 Clevis Pin .368 x .373 x 3.25 4
23 05503600 Bushing-Flange .372 x .500
x .312 x .750 8
24 02747600 Roller Clevis (046,053,055
306,307,308,310) 4
25 02745400 Roller (046,053,055,306,
307,308,310) 4
26 07412900 Screw-Tapping .38-16 x .50 3
27 05958000 Bolt-Hex .38-16 x 1.25 Gr. 5 1
28 06535900 Nut-Hex-Jam .375-16 1
29 06529600 Nut-Locking-Center .38-16 1
30 05948700 Bolt-Hex .38-16 x 1.00 Gr. 5 1
31 02736600 Adjusting Arm 1
32 02736800 Front Bracket 30”
(054,056) 1
