Mower Engagement Linkage
Models 927046,053,054,055,056,306,307,308,310
ITEM PART DESCRIPTION QTY.
NO. NO.
ITEM PART DESCRIPTION QTY.
NO. NO.
1 06529800 Nut-Locking-Center .31-18 11
2 06436700 Washer-Flat-Steel .323 x
.625 x .062 1
3 00325400 Wave Washer (055,308) 1
4 00607100 Spacer Bushing .5 x .32 x .21 1
5 06529600 Nut-Locking-Center .38-16 1
6 02720600 Rod Pivot (051,305) 1
7 06435700 Washer-Flat-Steel .38 x
.875 x .083 2
8 08319100 Spring-Compression .148 x
.68 x 6.5 (055,308) 1
9 02727100 Clutch Rod (055,308) 1
10 02721000 Arm (055,308) 1
11 06439400 Washer-Flat-Steel .328 x
.875 x .062 2
12 06437200 Washer-Flat-Steel .344 x
.688 x .065 (55,308) 1
13 07411500 Screw-Tapping .31-18 x .50 3
14 05947800 Bolt-Hex .31-18 x .875 2
15 02720400 Deck Pivot Bracket (055,308) 1
16 01035800 Spacer Bushing 1
17 08301000 Spring-Tension .072 x .51 x
5.31 1
18 06707300 Pin-Cotter .12 x .75 1
19 06706900 Pin-Cotter .09 x .75 3
20 02751100 Clutch Rod Right Hand
(055,308) 1
21 06529400 Nut-Jam .38-16 1
22 06515500 Nut-Cuplg Right Hand & Left
Hand Thread .37-16
(055,308)
1
23 06539000 Nut Left Hand Thread Gr. 2
.375-16 (055,308) 1
24 02751200 Clutch Rod Left Hand
(055,308) 1
25 06537300 Nut .50-13 (055,308) 1
26 06306600 Washer-Lock .500 x .151
(055,308) 1
27 02719500 Front Anchor (055,308) 1
28 05947000 Bolt-Hex .31-18 x .75 Gr. 5 7
29 02709700 Mower Adjustment Bracket 1
30 02507400 Cap Screw (046,053,054,056,
306,308,310) 1
05958900 Bolt-Hex .50-13 x 1.25
(055,308) 1
31 52709500 Clutch Rod Service Assembly
(055,308) 1
32 08309900 Spring-Tension .92 x 69 x 1
1.75
33 02712900 Shoulder Bolt 1
34 02715700 Shaft 1
35 07534300 Knob, 1.4 Dia. .50-13 1
36 02758351 Mower Clutch Lever 1
37 02704400 Clutch Arm 1
38 01212800 Flange Bushing 1
39 02706800 Link 1
40 02705700 Clutch Link 1
(046,053,054,056,306,307,310)
02719600 Clutch Link (055,308) 1
41 07412000 Screw-Tapping .25-20 x .50 2
42 05801600 Pin-Roll .188 x 1.00 1
43 02716300 Adjustment Yoke 1
(046,053,054,056,306,307,310) 1
44 06439200 Washer-Flat-Steel .505 x
1.000 x .062 1
45 02507200 Lock Spring 1
(046,053,054,056,306,307,310) 1
46 07412100 Screw-Tapping 10-24 x .375 2
47 01206300 Blade Brake 1
48 06437500 Washer .328 x 1.0 x .094 1
49 02708800 Brake Bracket 1
(046,053,054,056,306,307,310)
50 02705500 Pivot Bracket (054,056) 1
51 02709400 Mower Engagement Link 1
(046,053,054,056,306,307,310)
52 02509400 Brake Clip (054,056) 1
53 06801600 Rivet .25 x .50 1
(046,053,054,056,306,307,310)
54 02708900 Mower Brake Lever 1
(046,053,054,056,306,307,310)
55 02709300 Clevis Pin .306/.311 x 3-1/2 1
(046,053,054,056,306,307,310)
56 02709200 Mower Engaging Arm 1
(046,053,054,056,306,307,310) 1
57 02709100 Mower Brake Link 1
(046,053,054,056,306,307,310) 1
52708900 Mower Brake Link Service 1
Assembly
(046,053,054,056,306,307,310)
58 06701000 Pin-Hair Internal .08 x .38
x 1.42 1
