Ariens 927055 - RM1332 - Manual (Page 15)

13
Engine and Belts
Models 927046,053,054,055,056,306,307,308,310
ITEM PART DESCRIPTION QTY.
NO. NO.
ITEM PART DESCRIPTION QTY.
NO. NO.
1 08251600 Engine - 9.0 HP B & S I/C
(053,054,306) 1
08251700 Engine - 13 HP B & S I/C
(055,056,307,308)
08260300 Engine - 10 HP B & S non I/C
(046,310)
2 02755400 Pre-Guard-Rewind (306,307,
308,310) 1
3 06529800 Nut-Locking-Center .31-18 5
4 02749600 Nipple 1
5 03563600 Pipe Cap 1
6 05952400 Bolt-Hex .31-18 x 1.50 Gr. 5 4
7 06439400 Washer-Flat-Steel .328 x
.875 x .062 9
8 06602100 Key-Straight .25 x 2.0 x .25 1
9 02701000 Engine Sheave 1
10 07211200 V-Belt 3L-Section 35-1/2 x
27/64 1
11 02755700 Guard (306,310) 1
12 07412100 Screw-Tapping 10-24 x .375
(306,310) 1
13 06408300 Washer-Flat-Steel .505 x
1.140 x .250 1
14 06310700 Washer-Lock .438 x .133 1
15 05964800 Bolt-Hex .44-20 x 1.25 Gr 5 1
16 07216900 V-Belt HA 64.56 x .516
(046,053,054,056,306,307,310) 1
07215500 V-Belt 4L-Section 64-3/4 x
17/32 (055,308) 1
17 06529600 Nut-Locking-Center .375-16 1
18 02714000 Shoulder Stud 1
19 02700600 Idler Arm 1
20 06212100 Bolt-Round Head Square
Neck .31-18 x 1.50 1
21 00325400 Wave Washer 1
22 06436000 Washer-Flat-Steel .505 x
.875 x .024 1
23 06706900 Pin-Cotter .09 x .75 1
24 07321600 Idler-Flat 2.75 x .31 1
25 05947000 Bolt-Hex .31-18 x .75 Gr. 5 1
26 08319200 Spring-Tension .062 x .72
x 6.65 1
27 02509200 Belt Finger Brace 1
28 06530400 Nut-Flange .312-18 3
29 02504400 Belt Finger 1
