Figure 7
Remove the Manometer :
Turn main switch to the off position
Remove the manometer and re tighten the screw (Figure 7)
(Note: Do not over tighten the screw only snug is needed)
OVEN SERVICE PROCEDURES
Multi-Valve Adjustment Procedure
All Oven Models Natural Gas
LP Gas
Primary
Closed
Closed
Secondary
1.5
1.5
Burner Shutter Settings
Air Shutter Settings
Primary
Secondary
