SCB-1 Pin
Assignment
R
4
J6 Serial Control (RS-232)
Board side: JST S3B-ZR
Cable connector housing: JST ZHR-3
Pin 1
RxD
RS-232C, 9600baud, 8, n, 1 (Data from host)
Pin 2
TxD
RS-232C, 9600baud, 8, n, 1 (Data to host)
Pin 3
GND
The baud rate is changeable up to 921600 baud for image transfer.
J18 Power
Board side: JST S2B-ZR
Cable connector housing: JST ZHR-2
Pin 1
+12V DC; (0.5A typical, 0.7A max)
+/- 10%
Pin 2
GND
