PLAYBACK SCENES & CHASES
MANUAL RUN SCENES:
1. When power is first turned on, the unit is in manual scene mode.
2. Make sure AUTO & MUSIC LED’S BUTTONS (FIGS. 8 AND 9) are off .
3. Select BANK (FIG.4), using the UP and DOWN BANK BUTTONS
(FIG.4) , that store the scenes you wish to run.
4. Press the SCENE BUTTONS (FIG.2) to run the scene you selected.
MANUAL RUN CHASES:
This function will allow you to manually step through all scenes in
any Chase.
1. Press the PROGRAM BUTTON (FIG. 6) for three (3) seconds to
activate program mode. The LCD DISPLAY (FIG.3) will indicate
program mode by displaying a continuous fast blinking dot next
to ‘PROG.’
2. Execute a chase by selecting one of the eight CHASE BUTTONS
(FIG.5).
5. Press the TAP/SYNC BUTTON (FIG.11).
6. Use the BANK BUTTONS (FIG.4) to scroll through the chase.
Note:Display will show the number of the step in the Chase not
the Scene bank or number
AUTO RUN SCENES:
This function will run a bank of programmed scenes in a sequential
loop.
1. Press the AUTO/DEL (FIG.8) to activate Auto Mode. A flashing
light in the LCD DISPLAY (FIG.3) will indicate auto mode.
2. Use the UP and DOWN BANK BUTTONS (FIG.4), to select a bank of
scenes to run.
3. After selecting the bank of scenes you want run, you can use the
SPEED (FIG.13) and FADE (FIG.12) sliders to adjust the scene chase
Note: you can change banks, to run different scene sequences,
at any time by pressing the UP and DOWN BANK BUTTONS (FIG.4).
Note: when Adjusting fade time never make it slower than the
Speed setting or your scene will not be completed before a new step
is sent.
