WRM-10 USER’S MANUAL REV 2
13
The WRM-10 will continue to apply the test voltage on the transformer’s windings and
update the resistance values on the LCD screen. Press the
[CONTROL KNOB] to stop
the test.
f. The WRM-10 will automatically discharge the transformer and display the following
screen during the discharging process:
After the transformer is discharged, the test results will be displayed on the screen as
shown:
Press the
[CONTROL KNOB]
. You will be returned to the “MAIN MENU”.
R1 = 10.0 m Ω
R2 = 10.5 m Ω
DISCHARGE XFMR!
PLEASE WAIT...
