DIGITMR USER’S MANUAL

REV 3

3.8.3. Recalling a Timing Shot From the DigiTMR’s EEPROM

You can recall a stored test shot to the working memory by using the steps below:

a. Start from the “START-UP” menu:

Press the

[3]

key (SET-UP).

b. The following screen will be displayed:

Press the

[3]

key (SAVE / RESTORE).

c. The following screen will be displayed:

Press the

[2]

key (RESTORE SHOT).

d. The following screen will be displayed:

Using the numeric keypad, type the shot number that you would like to recall, and then
press the

[ENTER]

key.

e. The following confirmation screen will be displayed:

Press the

[ENTER]

key.

RESTORING SHOT #0001
TEST: OPEN
DATE: 04/21/09 09:27

“ENTER” TO CONFIRM

ENTER SHOT NUMBER
TO BE RESTORED
0000
“ENTER” TO CONFIRM

1. SAVE SHOT

2. RESTORE SHOT

3. SHOT DIRECTORY

4. ERASE SHOT

1. ANALYSIS POINTS

2. MEASUREMENT UNITS

3. SAVE / RESTORE

4. NEXT PAGE

1. TIME BRKR 04/17/09

2. GET RSLT 10:49:23

3. SET-UP

4. DIAGNOSTICS
