f. The following screen will be displayed:

Press the

[1]

key (Contact #1 CLOSE).

NOTES

Option details

• Contact #1 CLOSE

The open operation is initiated after contact channel #1 is closed. If this
option is selected, the DigiTMR will first initiate a CLOSE command and
then send an OPEN command only when it detects that the main
contact #1 is closed. This mode accurately simulates the closing of a
breaker on a fault condition.

• Set DELAY

A delay from 10 to 500 milliseconds can be set between the CLOSE and
OPEN command. When a delay is used in the operation, it may not
represent a true breaker operating condition.

• No DELAY

Both the CLOSE and OPEN commands are initiated by the DigiTMR
simultaneously.

g. The following screen will be displayed:

Press and hold down the

[ARM]

switch, and then press the

[START]

key. Continue to

hold down the

[ARM]

switch.

h. The following screen will be displayed during testing:

Continue to hold down the

[ARM]

switch until the test is completed.

i. Once the test is completed, you will be returned to the “START-UP” menu.

Test in Progress
Hold “ARM” until
test complete.
(Up to 25 seconds)

CLOSE-OPEN TIMING
Hold “ARM” switch,
then “START”.
“STOP” to ABORT

C-O Second Trigger:
1. Contact #1 CLOSE

2. Set DELAY

3. No DELAY
