DIGITMR USER’S MANUAL

REV 3

3.6.3. Checking Cable Hookups

To check the cable hookups:

a. Start from the “START-UP” menu:

Press the

[4]

key (DIAGNOSTICS).

b. The following screen will be displayed:

Press the

[2]

key (CHECK HOOKUP).

c. The following screen will be displayed:

Press the

[START]

key.

d. The test results will be displayed on the screen as shown below and also printed on the

thermal printer:

NOTE

A contact closure is shown as “C” on the screen and on the printout. An open
contact is shown as “-“ on the screen and on the printout.

1 2 3
C - -

MAKE SURE BREAKER IS

IN CLOSED POSITION

THEN PRESS “START”

1. SLOW CLOSE TEST

2. CHECK HOOKUP

3. TEST TRANSDUCER

4. NEXT PAGE

1. TIME BRKR 04/17/09

2. GET RSLT 10:49:23

3. SET-UP

4. DIAGNOSTICS
