REV 3 DIGITMR USER’S MANUAL
32
3.6.2. Performing a Transducer Self-Test
The transducer electronics can be checked by connecting the transducer to the DigiTMR and
running a “Test Transducer” diagnostic test. To test the transducer:
a. Start from the “START-UP” menu:
Press the
[4]
key (DIAGNOSTICS).
b. The following screen will be displayed:
Press the [3] key (TEST TRANSDUCER).
c. The following screen will be displayed:
Move the transducer slider and observe the DigiTMR’s display. The transducer’s
movement will be displayed in inches and degrees. If the transducer slider is moved 1.00
inch, the DigiTMR should display 1.00 inch.
Press the
[STOP]
key to end the test and return to the “START-UP” menu.
TRANSDUCER TEST:
1=000.00 IN / 000.0
x
2=000.00 IN / 000.0 x
3=000.00 IN / 000.0 x
1. SLOW CLOSE TEST
2. CHECK HOOKUP
3. TEST TRANSDUCER
4. NEXT PAGE
1. TIME BRKR 04/17/09
2. GET RSLT 10:49:23
3. SET-UP
4. DIAGNOSTICS
