Model ATRT-01 (v) Operating Instructions
Rev 02
May 02, 2002
6
Table 5-2: ATRT-01, ATRT-01B, and ATRT-01D Cable Set
Item Description Qty
1 Test-Lead Cable, 15-foot
Single-Phase Connections
1
2 Power Cord (Note 1) 1
3 RS-232C Cable 1
Note:
1. The ATRT-01D requires no power cord.
2. A Canvas Cable-Carrying Bag is included with the cable set.
6.0 Cable Marking and Identification:
Both H and X cable test leads are terminated with heavy-duty battery clips. Test cables are
identified as follows:
Table 6-1. Cable Markings and Identification
Test Cable Name Transformer Terminals Clip Color Identification
H Cables H Red H1, H2
X Cables X Black X1, X2
