1.4 Installation - Configuration
(continued)
J15/J4
1
J7
ET1
J16
Dev B
J15
Dev A
J7
ET1
J16
Dev B
J15
Dev A
J7
ET1
J16
Dev B
J15
Dev A
BAUD B BAUD A
BAUD B BAUD A
A D D R E S S
O N
D U M B
N O R M
Set Dumb/Normal switch
5
Normal - For all other networks
Dumb only for pre Network+ (pre 1985)
e.g.
Set modem/terminal adaptor baud rate 6
move link to
set baud rate
(Baud B)
e.g 19k2
set baud rate to maximum baud rate of modem
or terminal adaptor up to 19k2.
Modem or Terminal Adaptor Baud Rate = R2
Connect to local device - if direct connected to single device 7
(for Old IQs or local configuration)
J15 (TMNE)
J4 (TMNH, TMNG)
10 Way Female Molex
links between pins 2-4, 3-5
CABLE/EJ100179A001
25 Way D type Female
(old IQ)
BAUD B
= R2
TMNE
= R2
Modem or
Terminal Adaptor
Dev A
Dev A
black sheath
Note: Connecting a cable to Dev A connector disables Lan A communications
NOTE THAT BAUD RATE MUST BE 19k2
(default) FOR TMNH, TMNG
