7 3xtend/EINC L/230 Installation Instructions TG200812 Issue 3 3/9/08
Installation Instructions 3xtend/EINC L/230
1 2 3 4
R S 2 3 2 R x T x O K
O K L O N
1 2 2 8 - 3 6 V 2 4 V E T H E R N E T T R E N D L A N T - T + R - R + L I N K D A T A
L O N O K L O N T E R M A D D R E S S - B A U D S R V P I N
1 2 3 4 5 6 7 8 9 1 0
L A N
M A C A d d r 0 0 . 1 0 . 7 0 . 0 0 . U D . B B
O / S
S / N o : Q 3 B _ _ _ _ X 7 3 0 1 0 0 0 3 I P A d d r L o c a t i o n
M A C A d d r 0 0 . 1 0 . 7 0 . 0 0 . U D . B B S / N o : Q 3 B _ _ _ _ X 7 3 0 1 0 0 0 3 X T N D - 4 0 0 0 0 7 0 9 6
I P A d d r
3 X t r e a m
1.4 INSTALLATION - CONFIGURATION (Continued)
T e r m i n a t o r
T e r m i n a t o r
T e r m i n a t o r
Star topology
Bus topology
Loop topology
*Terminate L ON W ORKS bus at one end only
*
LonA SCN LonB
3xtend/
EINC L
A
1
IQLROUTER
2 3 4
B
1 2 3 4
IQL
x y
A
1
IQLROUTER
2 3 4
B
1 2 3 4
z w
IQL
x y z w
IQL
x y z w
IQL
x y z w
Recommend terminate at 3xtend/EINC L using L ON W ORKS terminator link
Otherwise terminate elsewhere using LONTERMINATOR. Terminate
L
ON W ORKS network at one end only.
Lon - FTT (free topology)
*
*
Do not allow wires to
cross on a loop
Maximum 64 nodes per L ON W ORKS
segment
Maximum 40 IQLs (and LONCs)
per virtual Lan
Terminated using IQLRouter’s L ON W ORKS terminator link
100 m F, 50 V min
100 m F, 50 V min
Terminator
Terminated using IQLRouter’s L ON W ORKS terminator link
6
SET L ON W ORKS Bus Terminator Link (Continued)
0
I 3
Install DHCP Server
7
If the IP address settings (IP address, subnet
mask, default router, and WINs server) are to be
supplied by a DHCP server install one on the
system if one is not already installed.
Switch On Read Licence
9
Read and agree to End User
Licence Agreement (these
instructions Section 2).
10
The 3xtend/EINC L will attempt
to obtain its IP address settings
Install WINS Server
8
If host names are to be used to connect to the
3xtend/EINC L install a WINS server on the system
if one is not already installed.
Check Status LEDs
11
Power LED
Ethernet OK LED
Lon OK LED
Current Loop OK LED
RX LED
TX LED
Ethernet Data LED
Ethernet Link LED
Power LED Ethernet OK LED Lon OK LED Current Loop OK LED + + +
Normal Operation Indication (shown after 2 minutes)
If LEDs are not as above after 2 minutes check table below.
from a DHCP server if one does not exist
it will go into link/local mode.
LED Continuously Flashing Off Continuously
Power (Blue) Unit Healthy Flashing twice repeatedly
IP address is not available, there will be no Ethernet
communications
< 300 s - Obtaining Ethernet settings.
> 300 s - Unable to obtain Ethernet settings
(Check for faults elsewhere).
Flashing repeatedly unit has a fault check other
LEDs.
If all 3 green LEDs are also flashing-invalid address.
Power Fault
Unit Faulty
