1.3 INSTALLATION - FIXING (Continued)
Replace Cover
10
a
b
1.4 INSTALLATION - CONFIGURATION
Fix Unit
1
3xtend/EINC L/24
Installation Instructions
section 1.3
Switch off
2
O
I
1
Note that this product may involve
L
ON W ORKS system integration. This
procedure should only be performed by
an installer with L
ON W ORKS expertise.
!
1 2 3 4 5 6 7 8 9 1 0
Remove Cover
3
1 2 3 4 5 6 7 8 9 1 0
WARNING: Opening the panel may expose
dangerous voltages.
417-IEC-5036
Caution: This unit contains static sensitive devices.
Suitable anti-static precautions should be
taken throughout this operation to prevent
damage to the units.
a
b
c
WARNING: The connecting leads may be
connected to supplies. Isolate before
touching.
BS EN100015/1 Basic Specification: protection of electrostatic
sensitive devices.
