TIF ZX Heated Pentode Refrigerant Detector User Manual
Page 5
3
1 . ON/OFF key
2 . Sensitivity high/low key
3 . Reset key
4 . Alarm key
5 . Constant power indicator (1st LED)
6 . Visual leak size indicators (2nd-6th LEDs)
PaRts anD contRols
1
2
3
Fig . 1
6
12
10
9
11
5
7
8
4
7 . Sensor (not pictured)
8 . Flexible probe
9 . Probe tip
10 . Filter cartridge
11 . Charger input jack (underside)
12 . NiMH battery pack
