Agri-Fab 45-0460 - Manual (Page 3)

3
NOT SHOWN FULL SIZE
SHOWN FULL SIZE
A B C
G
J K
I
E
D
H
N O
L
M
F
KEY QTY. DESCRIPTION
A 4 Hex Bolt, 5/16 x 2"
B 6 Hex Bolt, 5/16 x 1"
C 2 Hex Bolt, 1/4 x 3/4"
D 4 Nylock Nut, 1/4"
E 8 Nylock Nut, 5/16"
F 4 Nylon Washer
G 2 Flat Washer, 1/4"
H 4 Flat Washer, 5/16"
KEY QTY. DESCRIPTION
I 4 Spacer, .31 x .56 x .36"
J 3 Cotter Pin, 1/8 x 1-1/4"
K 1 Agitator Hairpin
L 1 Coupler
M 2 Seal
N 3 Nylon Tie
O 2 Angle Bracket
