6
920457 Rev B
USING QUALIPHY MOST50 EPHY
QualiPHY MOST50 ePHY guides the user, step-by-step, through each of the tests described in the
specification: MOST Electrical Physical Layer Specification Rev. 1.1, 06/2006, Version 1.1-00. To do
this, the user must set up a test session.
Users choose the test configuration they wish to run. There are six pre-loaded test configurations. They
are:
• All Tests [demo]
• All Tests [timing-master device]
• All Tests [timing-slave device]
• Compliance Tests [demo]
• Compliance Tests [timing-master device]
• Compliance Tests [timing-slave device]
These pre-loaded configurations provide quick and easy ways to begin compliance testing. If the user
does not want to run any of these configurations, they can create their own custom configuration (see
the following section entitled Customizing QualiPHY for details).
The pre-loaded configurations are set up to run all of the tests or just those required for compliance. If
this is not what the user wants, the variables can be modified (see the QPHY-MOST50e Variables
section of this manual).
The variables are pre-loaded with the standard settings for compliance testing; however, the user may
choose to create their own configuration with the variables set as desired.
