MOST50 EPHY MEASUREMENT PREPARATION
Before beginning any test or data acquisition, the oscilloscope must be warmed for at least 20 minutes.
Calibration is automatic under software control and no manual calibration is required.
This procedure will be run again if the temperature of the oscilloscope changes by more than a few
degrees.
QPHY-MOST50E TEST CONFIGURATIONS
Configurations also include variable settings and limit sets, not just test selections. See the QPHY-
MOST50e Variables section for a description of each variable value and its respective default value.
All Tests [demo]
This configuration runs a demonstration of all of the supported tests. All variables are set to default.
Saved waveforms are used.
All Tests [timing-master device]
This configuration is used for running all tests on a timing-master device. It is assumed that a differential
probe is used.
All Tests [timing-slave device]
This configuration is used for running all tests on a timing-slave device. It is assumed that a differential
probe is used.
Compliance Tests [demo]
This configuration runs a demonstration of the required compliance tests only. All variables are set to
default. Saved waveforms are used.
Compliance Tests [timing-master device]
This configuration is used for running the required compliance tests only on a timing-master device. It is
assumed that a differential probe is used.
Compliance Tests [timing-slave device]
This configuration is used for running the required compliance tests only on a timing-slave device. It is
assumed that a differential probe is used.
