Teledyne LeCroy QPHY-DDR3 User Manual
Page 12
12
917717 Rev C
1.
Connect the probe to the PCF200 Fixture.
2.
Press the Deskew Only button in the appropriate row representing the channel to be deskewed.
Now you are ready to probe the circuit and perform your measurements. If power is interrupted during
your measurements, reboot the oscilloscope and manually recall your settings.
