Operator's Manual
Text Fixtures
Telecommunications signals require specific load impedance for compliance testing to be accurate. The
twisted pair standards require 100 Ohm and 120 Ohm terminations, and the other standards require 75 Ohm
terminations. A set of adapters (test fixtures) for this purpose is available from Teledyne LeCroy (part number
TF-ET).
NOTE: These adapters require an additional LPA-BNC-ProLink adapter if they are being used with a
WaveMaster, LabMaster, or SDA.
Telecom Standard Required Termination Teledyne LeCroy Adapter
E1 TP 120 Ohm AP120
E1 coax 75 Ohm PP090
E2 75 Ohm PP090
E3 75 Ohm PP090
E4 75 Ohm PP090
STM-1E 75 Ohm PP090
DS-1 100 Ohm AP100
DS-3 75 Ohm PP090
STS-1 75 Ohm PP090
STS-3E 75 Ohm PP090
923136 Rev A 3
