LeCroy Corporation UWBTrainer Exerciser - Generation Script Language Reference Manual
7
7 Global Generation Settings
A generation script can define global parameters, called "generation settings", that affect aspects
of script compilation and execution. The generation settings are set using the Set script keyword.
7.1 Generation Settings
Currently the following settings are supported:
Setting Description
UwbTxPower
Specifies the level of transmitter power.
Possible values are
0 (no transmitting) to 15 (max level).
Default value: 15
UwbTxChannel
Specifies the wireless channel that UWBTrainer™ uses
to transmit WiMedia traffic.
The setting value for channel mapping
(see Figure 7.1 below) includes:
Band Group (3 bits)
TF Code (3 bits)
as specified in the WiMedia PHY Specification.
Default value: AUTO
(UWBTrainer uses the currently specified channel.)
UwbRxChannel
Specifies the wireless channel that UWBTrainer uses to
receive WiMedia traffic.
The setting value for channel mapping
(see Figure 7.1 below) includes:
Band Group (3 bits)
TF Code (3 bits)
as specified in the WiMedia PHY Specification.
Default value: AUTO
(UWBTrainer uses the currently specified channel.)
