Trademarks and Servicemarks
Teledyne LeCroy and Summit T3-16 and Z3-16 are trademarks of
Teledyne LeCroy. Microsoft and Windows are registered
trademarks of Microsoft Inc.
All other trademarks are property of their respective companies.
Changes
Product specifications are subject to change without notice.
Teledyne LeCroy reserves the right to revise the information in this
document without notice or penalty.
Teledyne LeCroy Customer Support
Online Download
Periodically check the Teledyne LeCroy Protocol Solutions Group
web site for software updates and other support related to this
product. Software updates are available to users with a current
Maintenance Agreement.
Mail: 3385 Scott Blvd., Santa Clara, CA 95054-3115
Web: teledynelecroy.com/Support/SoftwareDownload/
E-mail: [email protected]
Tel: (800) 909-7112 (USA and Canada)
Tel: (408) 653-1260 (worldwide)
© 2014 Teledyne LeCroy, Inc. All rights reserved. Part Number: 923899-00 Rev A
This document may be printed and reproduced without additional permission, but all copies should contain this copyright notice.
Connecting to the DUT and Generating Traffic
The Summit Z3-16 Exerciser Card can test both the host and device sides of a PCI Express link using the card alone or with
the Test Platform.
For Motherboards and Host Controllers
1. If not already powered off, power off the Summit Z3-16 Exerciser Card and the DUT.
2. Insert the edge connector into a PCI Express slot in the DUT. To connect to a x1, x4, or x8 slot, use an Edge Adapter.
For PCI Express Add-on Cards
1. If not already powered off, power off the Summit Z3-16 Exerciser Card, PCI Express Test Platform for Summit™ Z3-16
Exerciser with CLKREQ# and SRIS Support, and the DUT.
2. Insert the Exerciser Card into the PCI Express Test Platform for Summit™ Z3-16 Exerciser with CLKREQ# and SRIS
Support.
3. Insert the male edge connector of the DUT into the PCI Express slot.
Power on the Exerciser and then DUT
Important: Power on the Exerciser Card before you power on the DUT.
1. Power on the Exerciser Card.
2. If testing a motherboard, power on the motherboard.
3. Open the PETracer application on the host machine. The Exerciser is now ready for traffic generation.
Generating Traffic
1. Use the default settings or set options in the Generation Options dialog box (see Summit Z3-16 User Manual).
2. Start the PETracer™ software, if necessary, and open an existing script file or create a new script.
3. Start generation by clicking the Start Traffic Generation button on the Status bar. This action causes the software to
download the script to the device. After download completes, the device starts executing the script. As the script
executes, the Status bar displays script progress. Note: Script execution can be terminated at any time by clicking the
Stop Generation button on the toolbar.
Using a USB Connection
To set up the Exerciser using a USB connection:
1.
Install PETracer software on the host machine.
2. Connect the Exerciser to a 100-volt to 240-volt, 50 Hz to
60 Hz, 120 W power outlet using the provided power cord.
3. Connect the USB port to a USB port on the host machine
using a USB cable.
4. Power on the Exerciser by plugging the 12-V DC power cable
into the Exerciser Card and then into the PCI Express Test
Platform for Summit™ Z3-16 Exerciser with CLKREQ# and
SRIS Support.
Note: At power-on, the Exerciser initializes and performs a
self-diagnostic.
5. Summit Z3 will be recognized by the host machine as a USB
device.
Follow the Microsoft
® Windows ® on-screen Plug-and-Play
instructions for the automatic installation of the Exerciser as a
USB device on your analyzing host machine. (The required
USB drivers are included on the Installation CD and were
installed on your system when you installed the software.)
Click Finish when you see the message that says “Windows
has finished installing the software that your new hardware
requires” and the file has been installed in your host machine.
6. Start the PETracer software, so you can start working with
Summit Z3.
7
