Configuration
Use the tables below to configure the adapter for specific test situations.
SW1 Device Presence Table
SW2 Power Selection Table
SW3 Power Selection Table
Notes:
•
If using External Source, External DC Jack option must be
selected for both SW2 and SW3.
•
If using Host Source, Host option must be selected for both SW2
and SW3.
SW1.1 SW1.2 Presence Declared
ON ON Reserved
ON OFF X1 Device
OFF ON X4 Device
OFF OFF Reserved
SW2 Position 12V Power to Regulator
12V EXT From J4 DC Jack
12V HOST From PCIe Bus 12V
SW3 Position 3.3V Power to DUT
3.3V EXT From J4 regulated down to 3.3V
3.3V HOST From PCIe Bus 3.3V
