Teledyne LeCroy Automation API for PETracer/PETrainer
4
3 PEAnalyzer Object
The PEAnalyzer
object is a top-level object of PETracer™ API.
The PEAnalyzer
object allows user to control the recording and traffic generation, open trace files, and access
to the recording and generation options.
The PEAnalyzer
object supports the following interfaces:
Interfaces Description
IAnalyzer Facilitates recording and traffic generation, opens trace files,
and retrieves recording options,
IPEAnalyzer Extends the IAnalyzer interface:
Adds advanced generator functionality, retrieves generation
options.
IPEAnalyzer2
IPEAnalyzer3 Extends the IPEAnalyzer interface:
Adds hardware information and control methods.
Extends the IPEAnalyzer2 interface:
Adds StartImportFile method.
_IAnalyzerEvents Events from PEAnalyzer object
The IPEAnalyzer3 interface is a primary interface for the PEAnalyzer object.
The Class ID and App ID for the PEAnalyzer object are the following.
Class ID:
297CD804-08F5-4A4F-B3BA-779B2654B27C
App ID: CATC.PETracer
Example
WSH:
Set Analyzer = WScript.CreateObject( “CATC.PETracer” )
C++:
IPEAnalyzer* poPEAnalyzer;
// create PEAnalyzer object
if ( FAILED( CoCreateInstance(
CLSID_PEAnalyzer,
NULL, CLSCTX_SERVER,
IID_IPEAnalyzer,
(LPVOID *)&poPEAnalyzer ) )
return;
