Operator’s Manual
922209-00 Rev A 5
Specifications
Attenuation 1: 1 10:1
Bandwidth (MHz) 10 300
Input R (MΩ) 1 10
Input C (pF) 46 12
Compensation Range (pF) NA 10-35
Maximum Input Voltage 600 V (DC + AC
peak
) CAT II
Cable Length 1.2 m
Connector Type BNC
Operating Temperature 5° to 40° C
Storage Temperature -20° to 60° C
Humidity 5% to 85% relative humidity (%RH) up to +30° C
5% to 65% RH above +30° C to 40° C
5% to 45% RH above 40° C
Operating Altitude Up to 3000 m
NOTE: The maximum input voltage derates when frequency response is
approximately 30 kHz or higher. See Voltage Derating curve below.
Voltage Derating
