PP008 Passive Probe
4 922210-00 Rev A
Introduction
The PP008 is a miniature high impedance passive probe. Its high input resistance
and low capacitance make it ideal for general purpose probing of signals with
frequency content from DC through several hundred MHz. The PP008 has a large
selection of connection accessories, supplied standard with the probe and
available from Teledyne LeCroy as optional accessories.
The PP008 is designed for use with 600 MHz and lower Teledyne LeCroy
WaveRunner Xi series oscilloscopes.
Specifications
Electrical Characteristics
Attenuation

10

1%
Input Resistance 10 M
 
1%
Input Capacitance 9.5 pF
Input Impedance (see plot on next page)
Compensation Range 10 – 20 pF
Bandwidth 500 MHz (-3 dB)
Electrical Ratings*
Maximum Input Voltage Measurement category I: 400 V rms,
1250 V transient overvoltage
(see voltage derating curve on next page)
Measurement category II: 300 V rms CAT II
Pollution Degree 2
* See Certifications for an explanation of ratings.
General Characteristics
Operating Temperature 0
o
to +50
o
C
Storage Temperature -40
o
to +71
o
C
Altitude, Operating up to 2000 m (6560 ft)
Humidity 5% to 85% relative humidity (%RH) up to
+30° C 5% to 65% RH above +30° C to 40° C
5% to 45% RH above 40° C
Cable Length 1.3 m (4.3 ft)
Weight (probe only) 46 g
