Getting Started

7

Additional storage

MyPal A626/A686/A696 comes with the standard SD card slot. The SD

card slot can be inserted with SD or MMC memory cards. It also supports

SDIO cards of various functionalities including 802.11b/g, modem, etc.

Label

Installing and removing SD/

MMC/SDIO card

1. With the label side (usually the side with the

card manufacturer’s name) face up, and the

barcode/serial number side face down, insert

the card into the SD card slot located on top

of the device.

2. Push the card all the way into the slot until it

fits completely. If properly installed, the SD

or MMC card edge aligns with the top edge

of the device. SDIO cards usually have an

extended part that protrudes over the slot

edge.

3. To remove, press the card slightly until it

ejects out. You may then safely remove the

card.

NOTE

An SD/MMC/SDIO/ card fits only in one

orientation, and slides smoothly into the

slot if inserted correctly. DO NOT force

the card into the slot!

NOTE

Remove the car holder and take the device with you

when you leave the car.

Gently bend the gooseneck when adjusting the

orientation. Do not forcibly bend the gooseneck. The

device must be carefully placed into the holder to avoid

damaging the mini USB connector and causing the device

to breakdown.
