Appendix
31
OSD Factory Default Settings
Power On Self Test
When you turn the unit On, it undergoes a Power On Self Test. If there is a
problem, Port LEDs 1 - 4 flash repeatedly according to a pattern that indicates
what the problem is:
If any of these problems occur, turn the Switch Off, then turn it On again.
Setting Function
MULTIUSER MODE Enabled
ACCESS TIMEOUT 10 Seconds
OSD HOTKEY [Ctrl] [Ctrl]
DISPLAY MODE The Port Number plus the Port Name
DISPLAY DURATION 3 Seconds
SCAN DURATION 3 Seconds
Pattern Indication
On Line LEDs 1 - 8 Flash Simultaneously Internal RAM Memory Error
On Line LEDs 1 - 8 Flash One After the Other External RAM Memory Error
On Line LED pairs 1+2, 3+4, 5+6, and 7+8 Flash
One After the Other ROM Test Error
