1. Introduction
3
Requirements
Console
Š A VGA, SVGA, or Multisync monitor capable of the highest resolution
that you will be using on any computer in the installation.
If a monitor switches to a computer using a resolution that is higher than
the resolution that the monitor can support, serious damage to the monitor
may result.
Š A PS/2 style mouse
Š A PS/2 style keyboard
Š Microphone and Speakers (Optional)
Computers
The following equipment must be installed on each computer:
Š A VGA, SVGA or Multisync card.
Š A 6-pin mini-DIN (PS/2 style) mouse port.
Š A 6-pin mini-DIN (PS/2 style) keyboard port with +5V DC on pin 4 and
Ground on pin 3.
Cables
Use of substandard cables may damage the connected devices or degrade
overall performance. For optimum signal integrity and to simplify the layout,
we strongly recommend that you use the following high quality Custom Cable
sets:
Connector Type CS Custom Cable
Consoles 3 and 4 2L-1701S
PS/2 (6 pin mini-DIN) Keyboard and Mouse Ports 2L-1701P
Cascading to Second Stage Master View 2L-1601P
