WATTBOX™ 600 SERIES Installation and Users Manual
pg.9
© 2012 Wattbox ™
SPECIFICATIONS
Outlets
Type NEMA 5-15
Number of Outlets 12
Always On Bank 1 (4 Outlets)
IP Controlled Bank 2 (4 Outlets) Bank 3 (4 Outlets)
Display Link Outputs
Display Communication RJ45
Display Power NEMA 5-15
AC Power
Line Voltage 120V, 60Hz
AC Input Connection IEC C-14
Power Cord Length 6 Feet
Circuit Breaker Rating 15A
UL Current Rating 12A
Voltage Protection Rating (UL 1449 3rd Edition) 500V
Joule Rating 6480 Joules
Surge Component Ceramic Encased MOV
Protection Modes L-N, L-G, N-G
Peak Impulse Current 396,000A
Disconnect Circuitry Yes
Thermal Fuse Yes
EMI / RFI Noise Filtration
Filter Banks 1 & 2 53 dB, 1kHz to 1mHz
Filter Bank 3 (High Current) 80 dB, 1kHz to 2mHz
Safe Voltage Disconnect
Over Voltage 138 VAC + 5 VAC
Under Voltage 88 VAC + 5 VAC
Cable / Satellite Circuit
Connections Gold Plated “F” Connector
Surge Component Gas Tube
Clamping Voltage 600V
Frequency Range 0MHz - 3.0 GHz
Insertion Loss < 0.5 dB
Shielded Yes
Bi-directional Yes
Phone / LAN Circuit
Jacks RJ45
Accepts RJ11 & RJ45
Surge Component Sidactor & MOV
Clamping Voltage RJ11:400V; RJ45:250V
Wires Protected 8 Wires
UL Certifications UL 60950-1, UL 1449, UL 498, UL 497A/B, UL 1283
Dimensions 3.47” H x 17.02” W x 3.47” D
Connected Equipment Warranty $50,000
