WATTBOX™ 600 SERIES Installation and Users Manual
IP CONNECTIONS
After connecting the WB-600-IPVCE-12 to the network, configuration for IP control is performed using the Wattbox Utility. The utility
and documentation on configuring the Wattbox can be found on the included CD Rom and the SnapAV website (www.snapav.com).
Note: WattBox™ must be connected to the network and the router on before applying power to the WattBox™.
