Pg. 8
WATTBOX™ 600 Chassis Series Owners Manual
DC Trigger
Connections 3.5 mm (1/8”) mono mini plug
Input Voltage 3 - 24V DC, Bidirectional
Input Current 3mA @ 3V, 30 mA @ 24V
Pass-Through No Delay
Output Voltage 12V DC
Positive Tip
Negative Ring
UL Certifications UL 60950-1, UL 1449, UL 498, UL 497A/B, UL 1283
Dimensions 17.02”W x 3.47”H x 12.48”D
Connected Equipment Warranty $50,000
Dimensions
POWER
VOLTAGE CURRENT USB CHARGING
SAFE VOLTAGE PROTECTED GROUNDED
WB-600CH-SVCE-12
17.00in.
3.92in.
3.50in.
13.10in.
12.50in.
