Pg. 4
WATTBOX™ 600 Chassis Series Owners Manual
Positioning Options
The WattBox™ 600 Series is designed for placement on a shelf or mounting in standard 19” width equipment racks. Both
rack ears and feet are included so the decision can be made during installation.
Attach the feet or brackets to the WattBox™ depending on the desired application using the supplied hardware as
illustrated below.
POWER
VOLTAGE CURRENT USB CHARGING
SAFE VOLTAGE PROTECTED GROUNDED
WB-600CH-SVCE-12
Remove Feet for Rack Mounting
Attach Ears using Supplied Screws
(4 on Each)
Note: Rack ears can be mounted towards the rear of the unit to for easy connection access.
Securing Power Adapters
The WattBox™ 600 series is supplied with hook & loop straps that can be used to secure power adapters the outlets.
1. Remove the screw on both sides of the outlet.
2. Insert the screw in the eyelet on the hook & loop straps.
3. Tighten the screw to secure the strap.
4. Wrap the straps over the power adapter and tighten and fasten them together.
