Simplified mechanical drawing(x8 2ranks) – SP / Silicon Power SP002GBLRU800S01 User Manual
Page 6
DDR2 UDIMM w/o ECC
Product Specification
Rev. 1.1 Aug. 2011
6
Simplified Mechanical Drawing(x8 2Ranks)
X64 DIMM, populated as one physical rank of x8 DDR2 SDRAMs
Note: 1. All dimensions are in millimeters (inches); MAX/MIN or typical (TYP) where noted.
Note: 2. The dimensional diagram is for reference only.
