2
CHAPTER 2 INSTALLATION
2.1 Install Console to Cabinet
2.1.1 Before Installation
1. Before installation, please check all peripherals according to the list. Make sure the whole unit
was not damaged and lost during shipping process. If you encounter any problem, please
contact your local dealer.
2. Before installation, make sure all peripherals and computer have been turned off.
3. The standard brackets are for 504~1000mm (distance means front bracket to rear bracket)
cabinet, contact your dealer if you need more longer rear brackets.
2.1.2 Hardware Kits Contents
1. Rail with front and rear bracket x 2. (Please identify the brackets. Right and left sides are
different. For rack depth 504~828mm)
2. Long bracket x 2. (Needed for rack depth 828~1000mm)
3. Flat screw x 6 (for rail mount to console body)
4. Screw x 6
1. Key x 2
