LevelOne KVM-0117 - Manual (Page 11)

8
CHAPTER 3 PANEL CONTROLS AND OSD FUNCTIONS
3.1 Auto tune
Press the “auto” button. The panel will adjust the display size and position automatically.
This function is available only when you use a VGA input source.
3.2 Input Source
1. Press the “menu” button.
2. Use the “Down” and “Up” button to scroll, select “Input Source”.
3. Press the “menu” button to enter,and you will see:
VGA/DVI
4. Use the “Down” and “Up” button to select the input source of signal.
5. Press the “menu” button to enter.
3.3 Brightness
1. Press the “menu” button.
2. Use the “Down” and “Up” button to scroll, select “Brightness”.
3. Press the “menu” button to enter.
4. Use the “Down” and “Up” button to adjust the brightness of the display.
5. Press the “menu” button to enter.
Controls Description
Soft power on/off button. Adjacent LED is lit when on.
Auto
Auto-synchronize and scale down display to any valid factory
preset timings.
▲ Press to scroll the function you want to adjust.
▼
Press to scroll the function you want to adjust. When you’re not
in OSD menu, it can be a hot key to switch between DVI and
VGA video resource.
Menu
To access the main menu. This button also acts as the “Enter”
button.
