LAN Settings: When DHCP Server is disabled, users can specify IP address and subnet mask
for the CPE manually. Make sure the specified IP address is unique on your network in order to
prevent IP conflict. When DHCP Server is enabled, users may specify DHCP IP Address Range,
DHCP Subnet Mask, DHCP Gateway and Lease Time (15-44640 minutes). A DHCP relay
agents is used to forward DHCP requests and replies between clients and servers when they are
not on the same physical subnet. To enable the DHCP relay agent, check the “Enable DHCP
Relay ” checkbox and enter the IP address of the DHCP server.
In AP mode, the WAB-5120 300Mbps 5G Wireless Outdoor PoE Access Point/Bridge
must establish connection with another wireless device before it is set to Router mode.
To access the unit in Router mode via wired port, please type the WAN IP address to
enter the web page for WAN is on wired port and LAN is on wireless port. Or, you can
access device through the wireless device connected with the CPE.
In wireless client mode, users can access the CPE via its wired port, for WAN is on
wireless port and LAN is on wired port when device is set to Router mode.
Bridge mode and AP Repeater mode are similar to AP mode when device is set to
Router mode; WAN is on wired port and LAN is on wireless port. Thus users must also
connect the CPE with another wireless device before it is set to Router mode and
access the CPE via the connected wireless device.
Warning:
