1
LevelOne
User Manual
POT-xxxx Series
PoE Pepeater over 2-wire M/S
1. Introductions
The POT system, one master & one slave units, provide a long-reach Ethernet extension with remote
Power-over-Ethernet (PoE) capability over a 2-wire line. Connection with a Class 0 PD device, the distance
of two-wire 24AWG cables can be up to 300 meters when using a 48Watt high power PoE Switch,
FSW-0513/0543. Users may select a fixed data rate for different copper line ranging. The maximum data rate
can be up to 60 Mbps full duplex for 2-wire line.
The POT master unit is powered by the local PoE Ethernet network, and transmits both the data and power to
the remote slave unit over 2-wire cable. The remote unit regenerates the power and provides the PoE
capability to power up the remote PD device up to 15 watts when connecting to 48Watt High Power Switch,
FSW-0513. The POT M/S supports the indoor & outdoor models with wall-mount feature.
Equipped with dip switches, the 2-wire line speed can be configured to meet different line gauges and
distances. A POT pair offers a cost effective solution for remote power applications such as LAN-to-LAN
connectivity, Video Streaming, FTTB, and MDU/MTU over single twisted line.
IP-66
POT-1110 is IP66 is IP66-compliant meaning it is weatherproof from snow, rain, typhoon, desert heat, etc. this
PoE Repeater is up to the challenge for deployment in any harsh weather condition.
